Alfa Laval-Sharples DS-706 decanter centrifuges. 2020-11-10 14:58:41. Flottweg AC 2000 Beer Centrifuge. 2020-11-10 13:44:39. Solvent Extraction of CBD Oil from Hemp. 2020-10-16 16:21:50. Reconditioned Sharples P-5400 (PM70000) 2020-10-09 19:47:08. WHAT IS AN INDUSTRIAL CENTRIFUGE? An industrial centrifuge is a machine used for fluid/particle. The Sharples P-3400 Decanter Centrifuge is a horizontal de-sludging centrifuge built for the two-phase separation of crude oil tank bottoms, refinery slop sludge, industrial sludge-thickening, municipal sludge dewatering, paint sludge handling, etc. With a 25 HP Motor, the P 3400 decanter has a bowl RPM of 4,000 and can process 50 GPM on.
The Super centrifuge is a vertical high speed tubular bowl centrifuge, generating centrifugal force up to 20000 times the force of gravity. It is used either for continuous separation of two immiscible liquids having different specific gravities or for batch-wise clarification / polishing of liquids containing fine insoluble solids.
Sharples As16 Centrifuge Manual Download
Pennwalt Ltd. are manufacturers of high-G Tubular bowl Centrifuges model AS12, AS16 and AS26 based on the technology acquired from Sharples Stokes Division Pennwalt Corporation-USA.
Pennwalt also supply spare parts manufactured to international standards that are interchangeable on each of the above models of the high-G Tubular Bowl Super Centrifuge
This sectional view of a Super-Centrifuge shows the application of centrifugal force to a mixture of two immiscible liquids containing some suspended solids.
Sharples As16 Centrifuge Manual Free
The mixture continuously enters the Super-Centrifuge through an inlet feed nozzle at the base of the machine, into the hollow cylindrical rotor. Rotors have been designed and engineered to rotate at 17000 r.p.m. and generate centrifugal force of upto 20000 times the force of gravity.
This force separates the two liquids according to their specific gravities into concentric cylindrical layers, and the solids are deposited inside the rotating bowl against the rotor wall.
The separated liquids are continuously displaced upwards by the incoming mixture and continuously discharged through their respective outlet ports at the top of the rotor. The layer of accumulated solids that builds up on the inner diameter of the rotor wall is cleaned out batch-wise for which the super-centrifuge is shut down when it is filled up to the rotating bowl’s limiting solids holding capacity and the rotating bowl is removed for cleaning.
Sharples As16 Centrifuge Manual Instructions
Sharples As16 Centrifuge Manual Pdf
There are, however, many applications where only the removal of suspended solids from a single liquid is required. Super centrifuges for such applications are called Clarifiers and are often provided with only one set of discharge ports. Mylar Liners are optionally supplied and can be placed on the inner diameter of the bowl for ease of removal of insoluble solids deposited on the inner diameter of the bowl
